Red Lion E3-32DO24-1 I/O Module-32 24V Digital Outputs

Red Lion I/O Module-32 24V Digital Outputs: Output voltage range 10-30 VDC Max. output power: 0.5 Amps per channel, 8A per module Max. off state leakage: 0.01 mA (less than 10 uA) Short circuit protection: self-reset fuses (trip above 1.5 Amp) Min. load: 1 mA Inrush current: 5 Amps (100 ms surge) Typical on resistance: 0.3 Ohms (Drop 0.3 VDC @ 1 Amp) All channels Scan rate: 1 ms Operating Temp: -40 to 75 C Configuration: Crimson 3.x software, Graphical User Interface (GUI)
