Red Lion E3-8AO20M-1 Analog Output Module

Red Lion E3 I/O Module-8 Analog Outputs Analog output range 4-20 mA D/A resolution 16 bits (less than 1 uA) Full scale accuracy +/-0.02% (at 20°C) Span and offset temp. +/- 50 ppm per °C typ. Max. output settling time 5 ms (to .05%) Load resistance (@ 24 V) 0-750 Ohms Load resistance (@ 10V) 300 Ohms Operating temperature: -40 to 75°C MTBF: 1,433,249 Hours GB @ 40°C per MIL-HNDBK-217F2 Configured using Crimson® 3.x software Graphical User Interface (GUI) PN: E3-8AO20M-1
