Schneider Electric SCADAPack TBUT4203R2Y101UA1A Gas Flow Computer

SCADAPack 4203
TBUT4203 FUNCTION:Gas Flow Computer, integrated Multivariable Sensor and Controller, 2 Gas Flow runs, 32 Bit CPU
R I/O DESCRIPTION: 2 RS232/RS485, 1 Analog O/P (0-20mA), 1 RTD I/P, 1 Digital pulse/input/output, 1 Turbine Meter input
2 PROCESS COVER AND SENSORS: 316SS Process Cover. 316SS Sensor Material. Silicone Sensor
Fill Fluid. Stainless Steel Diaphragm. No NACE Compliant Certificate
Z DIFFERENTIAL ABSOLUTE PRESSURE MEASUREMENT
RANGE:
Differential Pressure:0 to 840 inH2O
Pressure: 0 to 1500psi
1 PROCESS COVER BOLT TYPE:
B7 - ASTM A193, Grade 7 bolts, ASTM A194 Grade 2H nuts.
Max. static pressure de-rated 25 Mpaa (3626 psia)
0 PROCESS CONNECTOR TYPE: 1/4" NPT, Threaded in Process Cover, with red plastic conduitcap
1 TRANSMITTER HOUSING MATERIAL:Epoxy covered Aluminum. Conduit Entry Sizes 1/2 - -14 NPT
U APPROVALS: C(CSA)us, Class 1 - Div 1 (Groups B,C,D) & Div 2 (Groups A,B,C,D). Hazardous Locations.
A PRELOADED APPLICATION SOFTWARE & LICENSE: RealFLO Gas Flow, supports up to 2 Gas runs
1 PROGRAMMING ENVIRONMENT: TelePACE Ladder Logic and C Language firmware - IEC enabled
A DIGITAL INDICATOR: Digital Indicator, Black Epoxy
