Vega B82.IXLFSAGBSHXKINXX VEGABAR 82 Pressure Transmitter

VEGABar 82 Pressure transmitter with ceramic measuring cell. Order code: 71890751 Scope: Worldwide Approval: for Ex-Free Area Process fitting / Material: Thread 1/2NPT, Inside 1/4NPT, ASME B1.20.1 / 316L Single seal sealing Measuring cell seal / Process temp: FKM (VP2/A) / -20C - 130C Measuring range: 0 - 0.1bar Pressure: Relative pressure (measurment against atmosphere) Accuracy Class = 0.20% Electronics: Two-Wire 4-20 mA/HART without Overvoltage protection and Supplementary Electronics Compact Plastic Single Chamber Hosuing. IP66/IP67; NEMA 4X Protection 1/2NPT Cable entry, Blind plug connection Foil Label without measurment loop identification label Measuring cell type: CERTEC - ceramic meauring cell Factor overload resistance measuring cell : 150 without Attached process seal Electronic differential pressure: Suitable configuration, -0.13bar - 10 bar Customs tariff number: 90262020
