Vega FX81.CDCTKFUXDNXX-181in Guided Wave Radar Level Sensor

VEGAFLEX 81 - Guided Wave Radar for measuring the level or interface of liquids. Order Code: US47771895 Scope: Canada Approval: CSA (XP-IS) CL I, II, III, DIV1, GP ABCDEFG Version / Material: Exchangeable cable (ø4mm) with centering weight / 316 Mounted Probe 181in from seal surface 3.973in rigid part Dimensions centering weight (dimater / height): 1.77in/1.18in (for 2'' Schedule 40 and 3'' Schedule 80/160) Process fitting / Material: Thread 2NPT PN40, ASME B1.20.1 / 316L FKM (SHS FPM 70C3 GLT) Seal, without Second line of defense, -40C to 150C process temperature Electronics: Four-wire Modbus (converter in second chamber) without Overvoltage protection of the supply cable, without Supplementary electronics Aluminium double chamber Housing, IP66/IP67(0.2bar) protection 1/2NPT Cable entry, Blind plug connection Foil label without measurement loop identification label -1bar - 40bar Process pressure Customs tariff customs: 90261029
