FreeWave ZumEdge ZU1100 Industrial Radio
Details
Frequency Range: 902 to 928 MHz
Output: Power Fixed at 1W
Range: 97 km (60 miles) with clear line of sight
RF Data Rates: 115.2 kbps fixed
I/O
Analog Inputs: 4-20mA
Analog Outputs: 4-20mA
Digital Inputs: 0 to 2.5 = Logic 0, 3.0 to PWC VDS = Logic 1
Digital Outputs: Isolated N.O. Switch Output
Power Supply: Operating Voltage +6 to +30 VDC
Current Consumption Voltage Transmit
Receive Idle 12 VDC 377mA 159 mA 143 mA
Data Connectors: Four Rj-45 (2 Ethernet, 2 Serial)
USB Connectors: Micro USB (used for configuration only)
RF Connector: TNC
Safety: Class 1, Division 2, Groups A-D
Output: Power Fixed at 1W
Range: 97 km (60 miles) with clear line of sight
RF Data Rates: 115.2 kbps fixed
I/O
Analog Inputs: 4-20mA
Analog Outputs: 4-20mA
Digital Inputs: 0 to 2.5 = Logic 0, 3.0 to PWC VDS = Logic 1
Digital Outputs: Isolated N.O. Switch Output
Power Supply: Operating Voltage +6 to +30 VDC
Current Consumption Voltage Transmit
Receive Idle 12 VDC 377mA 159 mA 143 mA
Data Connectors: Four Rj-45 (2 Ethernet, 2 Serial)
USB Connectors: Micro USB (used for configuration only)
RF Connector: TNC
Safety: Class 1, Division 2, Groups A-D
